Pepperl+Fuchs KCD2-STC-1.2O SMART Transmitter Power Supply With Good Price In Stock
1-channel signal conditioner
24 V DC supply (Power Rail)
Input for 2-wire SMART transmitters and current sources
Signal splitter (1 input and 2 outputs)
Dual output 0/4 mA ... 20 mA or 0/1 V ... 5 V
Terminal blocks with test sockets
Up to SIL 2 (SC 3) acc. to IEC/EN 61508
| General specifications | ||
|---|---|---|
| Signal type | Analog input | |
| Functional safety related parameters | ||
| Safety Integrity Level (SIL) | SIL 2 | |
| Systematic capability (SC) | SC 3 | |
| Supply | ||
| Connection | Power Rail or terminals 9+, 10- | |
| Rated voltage | 19 ... 30 V DC | |
| Ripple | within the supply tolerance | |
| Power dissipation | approx. 1.4 W at 20 mA transfer current, 250 Ω in both outputs | |
| Power consumption | 2 W | |
| Input | ||
| Connection side | field side | |
| Connection | terminals 1+, 2- (sink); 3+, 4- (source) | |
| Input signal | 0/4 ... 20 mA | |
| Voltage drop | terminals 3, 4: ≤ 6.1 V at 20 mA | |
| Short-circuit current | terminals 1+, 2-: 25 mA | |
| Input resistance | terminals 1+, 2-: max. 500 Ω (BRAIN) (250 Ω load) | |
| Available voltage | terminals 1+, 2-: ≥ 16 V at 20 mA , ≥ 18.5 V at 4 mA | |
| Output | ||
| Connection side | control side | |
| Connection | source: terminals 5-, 6+; 7-, 8+ sink: terminals 5+, 6-, 7+, 8- | |
| Load | channel 1: 0 ... 500 Ω (20 mA)/> 1 MΩ (5 V) channel 2: 0 ... 500 Ω (20 mA)/> 1 MΩ (5 V) | |
| Output signal | 0/4 ... 20 mA or 0/1 ... 5 V | |
| Ripple | max. 50 µA rms | |
| Transfer characteristics | ||
| Deviation | Iout < 20 µA (0.1 %); Vout < 7.5 mV (0.15 %) incl. calibration, linearity, hysteresis and fluctuation of supply voltage, at 20 °C (68 °F), 0/4 ... 20 mA, 0/1 ... 5 V | |
| Influence of ambient temperature | current output: 0.25 µA/K voltage output: 80 µV/K | |
| Frequency range | field side into the control side: bandwidth with 0.5 Vpp signal 0 ... 7.5 kHz (-3 dB) control side into the field side: bandwidth with 0.5 Vpp signal 0.3 ... 7.5 kHz (-3 dB) | |
| Settling time | 6 ms | |
| Rise time/fall time | 2 ms | |
