Pepperl fuchs HiD2030 SMART Transmitter Power Supply Part no:121495 With Good Price In Stock

Pepperl fuchs HiD2030 SMART Transmitter Power Supply Part no:121495 With Good Price In Stock

Model: HID2030

$1.00

Supplier: Pepperl+Fuchs

Categories: Explosion Protection

After sales service. If you have any questions, click here.

Product Description

Pepperl fuchs HiD2030 SMART Transmitter Power Supply Part no:121495 With Good Price In Stock


Pepperl + Fuchs HiD2030 2-channelisolated barrier for AAI143 AAI141 AAI841 SAI143 SAV144 is used for intrinsic safety applications. It provides 2-wire SMART transmitters with power in the hazardous area, and repeats the current to drive a safe area load.

Brand: Pepperl + Fuchs

Place of origin: Singapore / Germany


Pepperl+Fuchs is a leading supplier of automation equipment for a wide range of industries and has been associated with safety in hazardous areas for decades. Our deep expertise enables us to offer a complete range of automation solutions for the process automation industry.

1. General Introduction

Pepperl + Fuchs HiD2030 2-channelisolated barrier for AAI143 AAI141 AAI841 SAI143 SAV144 is used for intrinsic safety applications. It provides 2-wire SMART transmitters with power in the hazardous area, and repeats the current to drive a safe area load. Bi-directional communication is supported for SMART transmitters that use current modulation to transmit data and voltage modulation to receive data. The outputs are isolated from the inputs and are referenced to the power supply common. This module mounts on a HiD Termination Board.



2. Features

• 2-channel isolated barrier

• 24 V DC supply (bus powered)

• 2-wire SMART transmitter

• Output for 4 mA ... 20 mA or 1 V ... 5 V

• Low power dissipation

• Conformal coating

• Up to SIL2 acc. to IEC 61508


3. General Specification for HiD2030

Technical data

HiD2030

Supply

Rated voltage

20.4 ... 30 V via Termination Board

Power loss

1.5 W at 24 V (per channel)

Input

Input current

4 ... 20 mA, current limit 26 mA typ.

Input resistance

40 Ω , for current source

Ripple

10 mV eff

Voltage

min. 15.5 V at 20 mA

Communication

pass-through of HART signal to safe area The current sink terminals 4, 7   and 5, 6 do not pass the HART signal to safe area

Output

Load

0 ... 650 Ω

Output signal

4 ... 20 mA or 1 ... 5 V (on 250 Ω , 0.1 % internal   shunt

Ripple

10 mV eff on a load of 250 Ω

Response time

70 ms, 10 ... 90 % step change

Signal level

no fault: 1 mA ... 23.5 mA input current fault detection: < 0.2 mA or   > 24 mA input current

Transfer   characteristics

Calibrated accuracy

< ± 0.1 % of full-scale value (current output)

Influence of temperature

< ± 0.01 %/ K

Influence of load

< ± 0.1 % of full-scale value from 0 ... 650 Ω

Linearity

< ± 0.1 % of full-scale value

Ambient   conditions

Ambient temperature

-20 ... 60 °C (-4 ... 140 °F)

Mechanical   specifications

Protection degree

IP20

Mass

approx. 140 g

Dimensions

18 x 106 x 128 mm (0.7 x 4.2 x 5 in)

Data for   application in connection with Ex-areas

EC-Type Examination Certificate

CESI 02 ATEX 086

Statement of conformity

PF 11 CERT 2109 X

CSA approval

Control drawing

366-005CS-12B (cCSAus)


4. Selection tables

Termination Board & Barrier Module Selection table   for Yokogawa CENTUM VP DCS system

Yokogawa

Pepperl+Fuchs Termination Board

Pepperl+Fuchs Barrier Module

CENTUM VP

Channel

Class

Number of module

Type

Channel

Type

Selection of Digital   Input signals

ADV151

32

IS

32

HiCTB32-YC3-RRB-AK-CC-DX32

1

HiC2821

ADV151

32

IS

36

HiCTB16-YC3-RRB-AK-CC-DX32

2

HiC2822

ADV151

32+

IS

40

HiCTB08-YC3-RRB-AK-CC-DX32

4

HiC2824

Selection of Digital Output signals

ADV551

32

IS

32

HiCTB32-YC3-RRB-AK-CC-DX32-Y1

1

HiC2871

ADV551

32

IS

16

HiCTB16-YC3-RRB-AK-CC-DX32

2

HiD2872

HiD2876

Selection of Analog Input signals

AAl143

16

IS

16

HiCTB16-YC3-RRB-KS-CC-Al16

1

HiC2025

AAl143

16

IS

8

HiDTB08-YC3-RRB-KS-CC-   Al16

2

HiD2026

HiD2030

HiD2082

AAl143

16

IS

16

HiCTB08-YC3-RRB-AK-CC-   Al16

1

HiD2081

AAl141

16

IS

16

HiCTB16-YC3-RRB-KS-CC-   Al16-Y1

1

HiC2025

AAl141

16

IS

16

HiCTB16-YC3-RRB-KS-CC-   Al16-Y2

1

HiC2025

AAl141

16

IS

8

HiDTB08-YC3-RRB-KS-CC-   Al16-Y1

2

HiD2026

HiD2030

Selection of Analog Output signals

AA1543

16

IS

16

HiCTB16-YC3-RRB-KS-CC-AO16

1

HiC2031

AA1543

16

IS

8

HiCTB16-YC3-RRB-KS-CC-AO16

2

Hid2038Y

Selection of Analog Input and Output signals

AAI841

16

IS

16

HiCTB16-YC3-RRB-KS-CC-AM16

1

HiC2025

HiC2031

AAI841

16

IS

8

HiDTB08-YC3-RRB-KS-CC-AM16-Y1

2

HiD2026

HiD2030

HiD2032

AAI135

AAI835

8

IS

8

HiCTB08-YC3-RRB-KS-CC-AM08

1

HiC2025

HiC2031

AAI841

16

IS

16

HiCTB16-YC3-RRB-KS-CC-AM16-Y1

1

HiC2025

HiC2031

AAI841

16

IS

8

HiDTB08-YC3-RRB-KS-CC-AM16

2

HiD2026

HiD2038Y


5. Diagrams
